Mounting DC Motor Drivers
Mounting board for 4 DC Motor Drivers. Connects to Saxilby distribution board. PWM and IO are distributed from Scampton I2C PWM and I2C Welton IO Expander boards. Theoretically, it is possible to drive stepper motors as well, using two “DC motor” outputs.
Motor Power Break Out
Connect the driver mounting board to terminals via an 8 wire ribbon cable and 8 pin IDC plugs.
